Acetek designs, proto-types & manufactures electronic products for the signage industry including Surge-pro 80, Cyclops 232d. We can also provide complete electrical kits to illuminate back-lit signs or consultancy to specify high quality lamps and lighting ballasts in order to obtain maximum performance and reliability.

CELLOPTIK 300R DUSK TO DAWN PHOTOCELL Solar-Built PRODUCT
About Acetek
Acetek was incorporated early 2001 and has been actively trading since. The company is privately owned and operates under the instruction of the two directors. We supply quality electronic assemblies. We can supply either part or completed products all of which are manufactured within the UK using UK sources where ever possible. Acetek products are all independently tested to the relevant standards by ASTOR EMC. Every product is fully tested under load and inspected before dispatch. Acetek expanded its products by introducing a new range of slim modern suspended or surface mounted office luminares in both T5 and T8 single or twin lamps variants along with a range of slim LED backlit illuminated signs boxes.

Photo image of  CellOptik 24VDC
Dusk to Dawn Switch Solar-Built
 This standard photocell dusk to dawn switch uses a high quality relay to switch loads using "Silver-Tin Oxide" contacts to ensuring a long operational life. The mains operated sensor is rated at 300 watts and offers IP65 when installed correctly. In addition to the mains unit there is a 12 and a 24 volt DC version. Acetek uses solar energy when possible in the manufacturing process of these sensors to reduce carbon emissions. Sensors built using solar energy are clearly labelled with the Solar-Bulit symbol.
AceOptik is a new range of  office luminaires from Acetek
Product code

Operating voltage

Price

CellOptik 300R

240v AC 1.5A

£9.93 each

CellOptik 12VDC 5amp

12v DC 5A

£14.37 each

CellOptik 24VDC 5amp

24v DC 5A

£15.52 each

SignOptik is a new range of backlit signs from Acetek

Please note the postage charge of £2.00 on the secure payment method is for 1st Class UK deliveries and standard for outside the UK, orders over 100 please contact acetek
Voltage
New LED's tube lights.

The white LED tubes use the latest low current high lumen output LED's. Pitched at 45mm apart they emit 5 Lumens per LED and with a viewing angle of 120 degrees they are suitable for backlighting signs, front or rear lighting glass shelves, boats, cars, caravans and any other 12V dc applications. The low voltage and current consumption allows these 12V dc tubes to be operated form batteries and solar installations. The battery supply must be within 11.8 and 12.5V dc if this can not be acheived a self regulating version is avaliable that will operate from 12v to 18V dc  A suitable power supply is available to operate these tubes on mains voltage up to a total of 15 watts.

 These tubes have a life expectancy of up to 50,000 hours
(Below unregulated add R to end of code and £0.50 to the price for regulated, output refers to lumens)

Tube data

Product code

Length

Wattage

No Leds

Output

 Price £

 LA0.8LEDW

 420mm

 0.8

 9

 45

 5.50

LA1.6LEDW

 820mm

 1.6

 18

 90

 8.50

LA2.4LEDW

 1220mm

 2.4

 27

 135

 11.50

PSU12VDC

 -----

 15

 -----

----

15.50








A3 Illuminated LED Backlit Sign

Acetek have designed a new LED illuminated A3 sign using 54 of the latest straw hat LED's consuming just 6 watts at 60 lumens per watt. The slim external frame is silver anodised aluminum measuruing only 48mm in depth with a removeable top section to change the poster. The sign operates at 12v DC and is supplied with a mains adaptor.

For prices and delivery contact acetek


Business Directory - attract the right results with Businessmagnet the online directory

UK Sale Items.

 Product

 Stock

Price £ each

Delivery Charge

 3.5mm Jack plug stereo version

 32

 £0.05

 £1.00

 PIC16c54c O/P through hole

 300

 £0.10

£1.00

Transformer 2x 0-6v  0.25VA Block

 200

 £0.50

 £1.00

Fuse 16A  38 x 10.3mm Bussmann

 100

 £0.27

 £1.00

M16 IP68 grey cable gland with nuts

90

 £0.20

£1.00

Heat sink 45 x 20 x 36 x 2.5mm

 25

 £0.50

 £1.00

BNC Crimp plug

 90

 £0.20

£1.00

If you would like us to send you a photo of one of the other items listed above just email us. Photos displayed will change every few days.
You can order 1 or the total stock just email us, we will send the invoice,  send either cheque or paypal.
Example,
2  x  3.5mm Jack plug  £1.10
10 x 3.5mm Jack plugs £1.50
